3D CAD FILES AND SPEC SHEETS

3D CAD files are provided in most formats including IGES, STEP, PRO/E, and SolidWorks.  Either search for a model by part number or use the menus to narrow down your selection.  When you find the part number you are looking for, click on the link and you will be guided through the process of obtaining the CAD model.  You can also view the 3D model in your web browser prior to download.

CAD Model Search
Part Number:
500 Series Leveling Casters - Levelers have their own part number and must be downloaded separately.
PART NO.DESCRIPTION
LC525CS-CB-PHNCS Option, Corner Baseplate, 2.5in Phenolic Whls, Plain Brg
LC525CS-CB-PXPCS Option, Corner Baseplate, 2.5in Poly Whls, Prec Brg
LC525SS-CB-PHNSS Option, Corner Baseplate, 2.5in Phenolic Whls, Plain Brg
LC525SS-CB-PXDSS Option, Corner Baseplate, 2.5in Poly Whls, Delrin Brg
LC525SS-CB-PXPSS Option, Corner Baseplate, 2.5in Poly Whls, Prec Brg
